Technical Specifications
General Specification
• 60 cm dishwasher
• Freestanding – White
• 12 place settings
• Energy Class: 4 Energy Stars
• Duration of the left-on mode: NO_FEATURE
• Noise level: 48 dB (re 1 pW), built-under
Programmes
• 5 programmes:
Intensive 70 °C, Auto 45-65 °C, Eco 50 °C, Quick wash 45 °C, Pre-Rinse
• 1 special options: Half Load
Features
• 4 cleaning temperatures
• ActiveWater hydraulic system
• DosageAssist
• AquaSensor, Load Sensor
• Detergent Automation
• BLDC motor for heat and drain pump
• Stainless steel/Polinox
• Alternating spray
• Regenerative electronics
• Self-cleaning filter system with 3-fold corrugated filter
• Time remaining indicator front
• LED colour on indicators red/red
• Electronic delay timer: 1-24 hours
• LED salt refill indicator
• LED rinse aid refill indicator
• Retractable rotary knob
Baskets and Racks
• Vario basket system
• Silver XXL baskets
• Rackmatic 3-stage
• 2 foldable plate racks in bottom basket
• Cutlery rack in top basket
• Cutlery basket in bottom basket
• 2 x cup shelves
• AquaStop – Prevent Water Leakage
Safety
• Childproof door lock
• Servo-lock
• Glass care system
Technical Information
• Dimensions of the product (HxWxD): 84.5 x 60 x 60 cm
Technical Information
General
Width of the product (mm) 600 mm
Height of the product (mm) 845 mm
Installation typology Built-under
Number of place settings 12
Water consumption 9.9 l
Total annual energy consumption 186.6 kWh
List of programmes Auto, Economy, Intensive, Pre-Rinse, Quick wash
Additional operational options half load
Digital countdown indicator
Noise level (dB) 48
Interior light
Removable top
Length electrical supply cord (cm) 175 cm
Length outlet hose (cm) 190 cm
Connectivity
Home Connect No
Construction type
Control panel shape Bosch initial class
Color / Material body White
Color / Material panel White
Construction type Free-standing
Door panel options Not possible
Drying system Inherent heat
Control panel shape Bosch initial class
Color / Material body White
Color / Material panel White
Construction type Free-standing
Door panel options Not possible
Drying system Inherent heat
Height of the product (mm) 845 mm
Hidden heating element
Installation typology Built-under
Removable top
Tub material Plastic
Water softener
Width of the product (mm) 600 mm
Size and weight
Height with worktop (mm) 815 mm
Number of Options 1
Adjustable plinth
Net weight (kg) 44.446 kg
Programmes
List of programmes Auto, Economy, Intensive, Pre-Rinse, Quick wash
Name, programme 1 Intensive
Name, programme 2 Auto
Name, programme 3 Economy
Name, programme 4 Quick Wash
Name, programme 5 Pre Rinse
Programme duration, programme1 (min.) 125-135
Programme duration, programme2 (min.) 95-160
Programme duration, programme3 (min.) 210
Programme duration, programme4 (min.) 29
Programme duration, programme5 (min.) 15
Reference programme Eco
Number of different wash temperatures 4
Temperature, programme 1 (°C) 70
Temperature, programme 2 (°C) 45-65
Temperature, programme 3 (°C) 50
Temperature, programme 4 (°C) 45
Temperature, programme 5 (°C) 0
Safety
Glass protection techn. Yes
Surge-back protect. installed Yes
Water protection system Total system
Consumption values
Glass protection techn.
Total annual energy consumption 186.6 kWh
Energy consumption (kWh) 0.85 kWh
Energy consumption, programme1 (kWh) 1.45-1.5
Energy consumption, programme2 (kWh) 1-1.6
Energy consumption, programme3 (kWh) 0.846
Energy consumption, programme4 (kWh) 0.8
Energy consumption, programme5 (kWh) 0.05
Water consumption, programme 1 (l) 12-15
Water consumption, programme 2 (l) 9-19
Water consumption, programme 3 (l) 9.9
Water consumption, programme 4 (l) 10
Water consumption, programme 5 (l) 4
Water consumption 9.9 l
Maximum temperature for water intake (°C) 60 °C
Connection
Connection rating (W) 2,400 W
Length electrical supply cord (cm) 175 cm
Current (A) 10 A
Length inlet hose (cm) 165 cm
Length outlet hose (cm) 190 cm
Plug type GB plug
