Technical Specifications
Design:
- Appliance colour: stainless steel
- Wall mounted hood
Comfort:
- Suitable for ducted or re-circulated extraction
- 3 speeds
- push buttons for extractor speeds and light
- Metal grease filter, dishwasher safe
- Charcoal filter
Environment and Safety:
- Energy Efficiency Class: D*
- Lighting Efficiency Class: A*
- Grease Filtering Efficiency Class: C*
- Average Energy Consumption: 72.8 kWh/year*
Technical Info:
- Maximum extraction rate exhaust air 380 m³/h according to EN 61591
- Extraction rate in recirculation mode:
Max. normal use: 235 m³/h - Noise min./max. Normal Level: 53/64 dB*
- Noise level in recirculation mode:
Max. normal use: 70 dB(A) re 1 pW (56 dB(A) re 20 µPa sound pressure) - Power rating: 135 W
- Light Intensity: 1000 lux
- Colour Temperature: 4000 K
Measures:
- Electrical cable lenght 1.2 m
- Diameter pipe Ø 150 mm (Ø 150 mm enclosed)
- Dimensions exhaust air (HxWxD): 790 – 1015 x 598 x 470 mm
- Dimensions recirculating (HxWxD): 790 – 1015 x 598 x 470 mm
Technical Information
General
| Width | 60 cm |
|---|---|
| Depth of the product | 470 mm |
| Built-in / Free-standing | Built-in |
| Operating Mode | Convertible |
| Max. air recirculation (m³/h) | 235 m³/h |
| Sound pressure max. normal | 54 |
Construction type
| Diameter of air outlet (mm) | 150 mm |
|---|---|
| Colour | Stainless steel |
| Grease filter material | Washable aluminium |
| Grease filter type | Kassette |
| Installation type | Wall-mounted |
| Material of the body | Stainless steel |
| Material chimney | Stainless steel |
| Motor location | Integrated motor in hood body |
| Number of motors | 1 |
| Operating Mode | Convertible |
| Typology | Chimney |
