Key Features:
| 8 10/100/1000Mbps auto-negotiated RJ45 ports |
| Supports IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode |
| 4K entry MAC address table and automatic address learning |
| Auto-MDI/MDIX eliminates the need for crossover cables |
| Store- and-Forward Switching scheme |
Specification:
| Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x |
| Interface | 8*10/100/1000Mbps auto-negotiation RJ-45 Ports (Auto MDI/MDIX) |
| Power Supply | DC 9V/0.5A |
| Dimensions(L x W x H) | 5.2 x 3.0 x 1.0 in. (132 x 75 x 25mm) |
| LED | 1* Power, 8*LANs |
| MAC Address Learning | Auto-learning, auto-aging |
| MAC Address Table | 4K |
| Network Media | 10BASE-T: UTP Cat 3, 4, 5 cable 100BASE-TX/1000BASE-T: UTP Cat 5, 5e or above cable |
| Backup Bandwidth | 16Gbps |
| Transmission Method | Store-and-forward |
| Package Contents | S808G Desktop Switch *1 Power Adapter Quick Installation Guide *1 |
| Environment | Operating Temperature: 0℃~50 ℃ (32 ℉~122℉) Storage Temperature: -40℃~70 ℃ (-40 ℉~158℉) Operating Humidity: 5%~95% non-condensing Storage Humidity: 5%~95% non-condensing |
