Key Features:
Antenna: 2 x 5dBi |
Band: 2.4G Hz |
Speed: 300 Mbps |
Feature: 2000sqft Coverage, 15 ~ 25 Users |
Specification:
Device management | – Static Route – Routing Table – IP/MAC Binding |
FER (Frame Error Ratio) | – 11b 11M:-85dBm@8% PER – 11g 54M:-72dBm@10% PER – 11n HT20 MCS7:-68dBm@10% PER HT40 MCS7:-65dBm@10% PER |
Home | – Quick Setup – Basic setup – Advanced setup – QR Code – LED – Logout – Reboot |
Interface | – 4 *100Mbps LAN Ports – 1 *100Mbps WAN Port |
NAT | – Virtual Server(Port Forwarding) – DMZ – VPN passthrough |
Operation Mode | – Gateway Mode – Repeater Mode – AP Mode – WISP Mode |
Parental Control | – Internet time control based on MAC |
Security | – MAC Filtering – IP/Port Filtering – URL Filtering |
Tools | – Upgrade Firmware – Time Setup – Remote management – Password Settings – Reboot Schedule – System Log and so on |
WAN Type | – Static IP, DHCP, PPPoE/Russia PPPoE, PPTP/Russia PPTP, L2TP/Russia L2TP |
Wireless | – Basic setup – Guest Network(Multiple SSID) – Wireless Schedule – Access Control – Advanced setup |
Power Supply | – DC 5V/0.6A |
Button | – 1 *RST/WPS Button |
LED Indicator | – 1* System, 1* Wi-Fi, 1* WAN, 4* LAN |
Antenna | – 2 * external fixed antennas (2.4G) |
Dimensions (L x W x H) | – 134mm *76mm *24mm |
Wireless Standards | – IEEE 802.11b, – IEEE 802.11g, – IEEE 802.11n |
RF Frequency | – 2.4~2.4835GHz |
Data Rate | – 2.4GHz: Up to 300Mbps |
EIRP | – < 20dBm |
Wireless Security | – WPA/WPA2 Mixed |
Network | – WAN Setting – LAN Setting – DDNS Setting – IPTV Setting – IPv6 Setting |
QoS | – Up/Down speed control on WAN, – Bandwidth control based on IP address |
Environment | – Operating Temperature: 0℃~50 ℃ (32 ℉~122℉)- Storage Temperature: -40℃~70 ℃ (-40 ℉~158℉) – Operating Humidity: 10%~90% non-condensing – Storage Humidity: 5%~90% non-condensing |
Package Contents | – N350RT Wireless Router *1 – Power Adapter *1 – Ethernet Cable *1 – Quick Installation Guide *1 |
Warranty | 1 Year Brand Warranty. |
