- COLORFUL C.H310M-E D3 V20 Intel LGA1151 Intel H310 Motherboard DDR3 1333 /1600MHZ VGA+HDMI PCI Express3.0X16 mATX SATA3.0 65WChipset: Intel H310
CPU: Support Intel LGA 1151 interface Coffee Lake-S series processor (TDP: 65W)
Board Display Interface: VGA+HDMI
Hard Disc Interface: 4 * SATA3.0 6Gb/s
Internal Memory Slot: 2 * internal memory slots for DDR3 dual channels 1333 /1600MHZ
Expansion Slots: 1 * PCI Express3.0 * 16; 1 * PCI Express2.0 * 1
USB Interfaces: 2 * USB2.0 2 * USB3.0
Network Card: RTL8111H gigabit LAN
Audio: ALC662
IO Chip: ITE IT8613E
BIOS: 64M UEFI for multi languages
PCB Size: 215 * 170mm mATX
Power Management: Support awaking S3 S4 S5; support RTC wake up and net S5 wake up Product description
Colorful H310M-E V20 featured with high performance. 6 protection technologies, more stable. 200 rigorous test processes, quality guarantee. Upgraded PCB automization technology.
Features: VGA+HDMI ports; 4*USB2.0 and 4*USB3.0 ports(include headers); Audio isolated LED light; Support S3、S4、S5 wake-up; Support phone call startup、timing boot、network S5 wake-up
Specification: Motherboard_Model H310M-E V20; Chipset H310; Processor support Intel LGA1151 Coffee Lake-S processors; Memory 2 DIMM slots,support dual channel DDR4 2133/2400/2666MHz memory; Graphics 1*PCI Express3.0X16 slot; Board_IO 2*PS2 ports,1*VGA port,1*HDMI port,1*RJ45 lan,3*audio ports,4*USB2.0 and 4*USB3.0(including headers); Expansion_Slots 1*PCI Express 2.0×1 slot; SATA_Ports 4*SATA3.0 6Gb/s ports
BIOS 64M UEFI; Power_Management support 65W processors; Hardware_Monitor CPU Fan speed Controlled,SYSTEM Fan speed Monitoring,CPU Temperature Monitoring,System Temperature Monitoring,and Voltage monitoring; LAN RTL8111H 1000M LAN chipset; Audio ALC662 6-channel audio chipset; Configuration 215 x 170 mm mATX; Other_Features Support S3, S4, S5,USB wake-up;Support phone call startup, timing boot, network S5 wake-up
Package list: 1 * Colorful iGame H310M-E V20 Motherboard 2 * SATA Cable 1 * Driver / Utility CD 1 * I/O Shield 1 * User Manual.
COLORFUL BATTLE-AX C.H310M-PT V20 Motherboard
৳ 6,200.00
- Supports 8th Generation Intel® Core™ Processors (Socket 1151)
- Supports Dual Channel DDR4 2133/ 2400 / 2666 / (XMP) MHZ memory
- 4*SATA3.0 ports
- RTL8111H 1000M LAN
- Realtek ALC662 6-ch audio chipset
- COM +VGA+HDMI +DVI ports
- 6*USB 2.0 and 4*USB 3.0 ports
- Audio isolated LED light
- Support S3、S4、S5 wake-up
- Support phone call startup、timing boot、network S5 wake-up
Out of stock
